G3 ATOM Switching System

Tax included.
Tax included for UK only. Ex VAT price displayed for all other shipping destinations


Due to the current ATOM wait list we have reintroduced the 50% deposit option so you can secure your place in the queue.
Select the 'Partial Pay' option and add the product to cart. At checkout you will pay an initial partial payment and you will receive a notification to pay any outstanding balance via email, 1 week prior to dispatch.

A new standard for effects pedal lovers seeking the ultimate control and tonal transparency.

G3 ATOM and G3 marks a new standard in pedalboard effects control. Built on the legacy of our award winning G2, G3 ATOM delivers the ultimate in signal path purity with possibilities never before seen in a pedalboard switcher.

We designed the G3 Atom alongside G3 from the ground up, obsessively testing and retesting every aspect of its design to ensure we delivered the most robust, fully featured, tonally transparent switching system in the world.

Hear your effects as they were designed to sound, unencumbered by compromises inherent in a standard pedalboard setup.

G3 ATOM is an expression of our passion. We compromised on nothing.

NEW! - G3 Bluetooth Web Editor!

Ships with a GigRig Generator Power Supply as standard - The heart of our Modular Power Supply range. Please select your desired mains power lead when adding to cart.

Choose to upgrade your power supply to the New Gen-X-14 DC Power supply when you add to cart and we'll swap out the Generator.

  • 99 Banks with up to 16 Pre-sets per Bank
  • Programable Pre Effects Loop Buffer/Boost
  • Programable Post Effects Loop True Stereo VCA Amplifier
  • 6 x True-Bypass passive Stereo effects loops
  • Fully movable loops - Reorganise your entire signal chain, Per Pre-set, in seconds
  • 2 x Programable Outputs one of which is transformer isolated and phase reversible to eliminate earth loops and phase problems when using two amps
  • Built in Parallel and Wet/Dry configuration
  • Send up to 20 x programable mappable PC/CC MIDI Messages per pre-set
  • 2 x Expression pedal inputs capable of controlling the onboard pre and post effect loop amplifiers as well as sending multiple MIDI CC messages, each with separate heel/toe values
  • Program Reverb and Delay Trails/Spillover from any loop or combination of loops
  • Simple intuitive programming via easily navigated built in menu system
  • Ultra clean signal path to ensure your guitar signal is as pure as possible
  • Bluetooth enabled - *Connect to G3 iOS app to update software, backup pre-sets, and edit song lists
  • High Resolution Ultra-Bright TFT LCD screen displaying Bank, Pre-set Number /Name and Pre/Post Gain levels and menu system (Brightness Adjustable)
  • Black anodized aluminium chassis – Light weight and hard wearing
  • Water resistant/ splash proof overlay with quick select, tactile embossed membrane switches
  • 8 x GigRig 'Optokick' Optical Footswitches - Designed by The GigRig, our footswitches use light instead of mechanics to do the foot switching and are milled from stainless steel, making them more robust than their mechanical alternatives. We believe these are the most reliable foot switches in the world.
  • FREE GigRig Generator Power Supply - The Heart of our Modular Power Supply range, with UK Mains lead included as standard.
  • Physical size: 29cm x 13cm x 7.8cm / 11.4" x 5.1" x 3.07"
  • Screen size: Approximately 5 x 3.8cm / 1.96"x 1.5"
  • Power Requirements: 9V DC (2.1mm centre neg) @ 850mA.We recommend the use of The GigRig Generator power supply supplied with The G3 Switching System.
  • Weight: 1.65kgs / 3.64lbs

The GigRig warrants the product to be free from defects in material and workmanship for a period of 2 years from the original date of purchase.

If the product fails within the warranty period, The GigRig will repair or, at our discretion, replace the product and cover the cost of return shipping to the original purchaser.

This warranty covers defects in manufacturing discovered while using this product as recommended by The GigRig.

This warranty does not cover loss or theft, nor does the coverage extend to damage caused by misuse, abuse, unauthorized modification, improper storage, lightning, or natural disasters.

Damage caused by any of the above circumstances may result in a non-warranty repair fee.

Legal: In the case of malfunction, the purchaser’s sole recourse shall be repair or replacement, as described in the preceding paragraphs. The GigRig will not be held liable to any party for damages that result from the failure of this product. Damages excluded include, but are not limited to, the following: lost profits, lost savings, damage to other equipment, and incidental or consequential damages arising from the use, or inability to use this product. In no event will The GigRig be liable for more than the amount of the purchase price, not to exceed the current retail price of the product. The GigRig disclaims any other warranties, express or implied. By using the product, the user accepts all terms herein.
